HELLION HAM 450.4D

TECHNICAL SPECIFICATIONS

Gain class Digital - D

Power RMS 1 Ohm 4x670W

Power RMS 2 Ohm 4x330W

Power RMS 4 Ohm 4x170W

2x1350W RMS 2 ohm bridge power

RMS 4 Ohm power 2x670W bridge

Frequency range 20Hz-20kHz

Signal to noise ratio 90 dB

Harmonic distortion coefficient 0,5%

Line level input sensitivity (RMS) 0.3-9V

Line level input impedance 20 kOhm

High level input sensitivity 8-40V

High level input impedance 13 ohms

Crossover: (Disable - Direct ) 12 dB/octave

HPF 20-20000Hz

LPF 35-20000Hz

High level input sensitivity RMS 2.5-40V

Voltage 9-16V

Built-in fuse 4x30A

Operating temperature range -30 \ +70℃

Protection class IP-54

Size 291(L) x 125(W) x 47.5(H) mm
