Hellion HAM 500.4D Optical Amplifier

technical specifications :

Digital Gain Class - D

Estimated RMS power of 1 Ohm 4X670W

RMS power of 2 Ohms 4X330W

RMS Power 4 Ohms 4X170W

Rated RMS power 2 ohms\Bridge 2X1350W

RMS Power 4 Ohms\Bridge 2X670W

Frequency range 20Hz-20kHz

Signal to noise ratio 95 dB

Harmonic distortion factor 0.5%

Sensitivity of line level inputs (RMS) 0.3-9V

The line level input impedance is 20 kOhm

High Level Input Sensitivity (RMS) 1-30V

The high-level input impedance is 100 ohms

Crossover: (switchable – Direct )  12 dB\Oct

HPF 20-20000 Hz

LPF 35-20000 Hz

Optical input/output PCM 24bit/192kHz

Voltage 9-16V

Built-in fuse 4x30A

Operating temperature range -30 \ +70℃

Protection class IP-54

Size 272(L) x 125(W) x 47.5(H) mm
